Munich 2 Data Center

Address Ammerthalstraße 10, 85551 Kirchheim bei München, Germany Space
Open Time Power
Owner e-shelter Air conditioning & Cooling
Contact +1 844-902-4100 ,N/A Standards
Data Center Introduction

e-shelter: Munich 2 Data Center

e-shelter Munich 2 Data Center is located at Ammerthalstraße 10, 85551 Kirchheim bei München, Germany. The data center is 193750 sqft. There is a total of 66736 sqft in raised floor space for colocation. It has access to 20 MW of power. We found 8 data center locations within 50 miles of this facility. Certifications for this location include PCI-DSS, ISO 27001, ISO 90001.

The Munich 2 data center is situated in the north of Munich, in Unterschleißheim approx. 16 miles as the crow flies from e-shelter’s Munich 1 site. The Munich 2 data center was planned as a dedicated data center new build and is being developed in several building stages. On a plot which is more than 193,750 sq feet large, about 66,736 square feet of data center space is being developed in two building stages. The first building stage was completed in May 2017.

The site was selected on the basis of an extensive risk analysis to satisfy the high requirements for security and availability. The provision of electricity, connection to data networks and protection against natural hazards were all given particular consideration here. In Munich 2, a cooling by groundwater is also used, which has been developed for maximum energy efficiency.

Power Supply
Power supply at 20 kV level from two substations from two separate feeds, two separate UPS systems (A- and B-supply) and redundant emergency power system with diesel generators
Security
Integrated alarm management, consistently documented access management and access control via non-contact chip and PIN or optional biometrics signature
Fire Safety
Early smoke detection systems (smoke extraction systems), which are integrated into the fire alarm system, guarantee the earliest possible detection even before fire and smoke fumes or fire develop
Connectivity
The e-shelter data center will be connected by at least ten carriers from several, redundant feeds and has two Carrier-Meet-Me-Rooms (CMMR)
