Global Switch 悉尼西翼数据中心

悉尼数据中心园区

有关 Global Switch Australia Holdings Ltd（一家合并后的 Global Switch 实体）拥有的悉尼数据中心园区的更多信息。

Global Switch 的悉尼校区位于澳大利亚金融和商业中心悉尼中央商务区的西部边缘。 园区设有两个数据中心 —— 悉尼东部和悉尼西部 —— 它们共有 73,000 平方米的专用世界级技术空间。

• 澳大利亚唯一的超大规模数据中心园区，位于悉尼中央商务区边缘
• 澳大利亚最多样化和网络最密集的电信生态系统之一，由多个交易所和四个地理位置不同的建筑入口点支持
• 无需中间连接的 73,000 平方米数据中心园区
• 80MVA 园区管理，具有运营可靠性和灵活性
• 从单机架部署到多兆瓦定制解决方案的灵活解决方案

连通性

由于靠近中央商务区，悉尼校区吸引了多元化和网络密集的电信业务，使其成为任何寻求建立中央商务区 PoP 的运营商的自然选择。 使用我们的结构化互连系统可以直接访问这些运营商和其他客户，该系统可实现跨园区的低成本连接。

基础设施

校园由新南威尔士州最大的私人高压网络之一供电，并且由于相邻的中央商务区电网的高可用性（以 33,000 伏特连接），供电可靠性得到进一步提高。 Global Switch Sydney 因卓越的运营而享有盛誉。 这一点，再加上其卓越的工程和战略位置，使校园成为许多世界上最大的电信、云和金融组织以及许多州和联邦政府机构的所在地。

更多信息

无论您是在寻求小型接入点还是定制的多兆瓦数据大厅解决方案，我们经验丰富的团队都可以随时为您提供建议并讨论您的选择。

悉尼东翼/悉尼西翼

400 Harris Street, Ultimo, Sydney, NSW 2007, Australia

Telephone: +61 2 9566 7000

salessydney@globalswitch.com

更多信息，请访问：https://www.globalswitch.com.au/locations/sydney-data-centres/

Location

• The data centre is located less than 1.5km from the financial district and city centre
• A local metro railway station is located within a 5 minute walk. Inner city tram and bus access is readily available
• Kingsford Smith Airport is 10km away

Building Overview

• Global Switch owns the freehold
• Purpose built
• Exceeds Tier III operational performance
• 41,575 sq m of gross space
• 7 data floors
• Flexible IT space with ability to create bespoke environments as required

Main Structural Features

• Reinforced concrete construction floors and columns, with spandrel panel walls and aluminium glazing panels
• Minimum 3.6m slab to slab height
• Raised floor height of 600mm
• Minimum from raised floor: 3.m clear height to underside of deepest beam
• Floor loading of 10kN/m²
• 1 goods lift (10 tonnes), 2 passenger lifts

Power

• 33kV utility supply with N+1 redundancy
• Utility power supply capacity of 35MVA (current)
• Technical (IT) power and mechanical systems supplied by on-site Diesel Rotary UPS with N+1 redundancy
• Fully diverse power distribution to technical areas
• On-site fuel storage to support 24 hours at full capacity with 24x7x365 fuel delivery
• Offering 1,000 W/m2 as standard, with higher power density solutions fully supported

Cooling

• 31.5MW of total cooling provision
• Minimum N+1 resilience on all systems
• CRAH units control temperature and humidity in technical space within the recommended range of ASHRAE TC9.9
• Diverse distribution pipework throughout
• Chilled water cooling system
• In rack cooling capability if required

Security

• Operations Centre manned 24x7x365
• Security guard patrols 24x7x365
• Continuous CCTV surveillance of external and internal areas
• CCTV records kept for 31 days
• Comprehensive intruder detection and alarms to all areas
• Strict access control procedures to ISO 27001
• Access control using proximity card readers and biometric systems
• Physical access via mantrap
• Secure managed delivery and loading area available 24x7x365
• Secure staging available, if required

Connectivity

• Carrier Neutral
• Network dense with access to multiple global and regional carriers and Internet service providers offering Dark Fibre, Wavelength, Ethernet, MPLS, VPLS, IP Transit, Peering, CDN, Storage, Virtualised Services (SDN), Voice and Mobile Services
• Access to multiple cloud services through leading public, private and hybrid cloud solution providers
• 4 dedicated Meet Me Rooms
• 2 diverse building entry points
• Diverse cable routes and pathways
• Campus fibre system interconnecting Sydney West to Sydney East
• Roof space availability for satellite and antennae equipment
• PipeIX, MegaIX and IX Australia present

Fire Detection and Suppression

• Analogue addressable fire detection system in all areas
• Aspirated early warning smoke detection system (monitored 24x7x365)
• Inergen gas suppression system in technical areas with dry pipe pre-action sprinkler for additional resiliency

Critical Environments Management

• Experienced 24x7x365 facilities management team
• Environment (thermal conditions) monitored 24x7x365
• All Building Management Systems (BMS) monitored 24x7x365
• Comprehensive energy metering systems
• Internationally recognised critical environments programme

Other Services

• Cross connects
• Customer reports
• Deliveries and storage
• Design and build
• Fit-out
• On-site facilities
• Remote hands
• Technical cleaning and waste disposal

Certifications

• ISO 9001, 14001, 27001, 45001, 50001
